Optimistic UI

The idea of “Optimistic UI” is based on the belief that most of the time the things your users do will be successful. So if they check off a todo, we can instantly mark it as complete in the client while the request is made to make the change because most of the time it will be successful. This makes the UI feel much faster.

Learn more about the concept of Optimistic UI from the end of my talk here:

useOptimistic

Transitions (like those you get from useTransition) prevent the UI from changing when the component is suspended. But sometimes you want to show a different UI while the component is suspended (and even change that UI multiple times while it’s in the suspended state).

This is where useOptimistic comes into play. It may even be better to call it useTransitionState instead! In any case, the idea is that useOptimistic is like a useState hook which will actually change the UI even while it’s suspended. It’s often used to implement Optimistic UI which is why it’s called useOptimistic.

Form Actions are automatically wrapped in startTransition for us so if you have a form action for which you would like to implement optimistic UI (which requires updating state), then you need to use useOptimistic to get around the suspended nature of the transition. Here’s an example of how it’s used with a Form Action:

function Todo({ todo }: { todo: TodoItem }) {
    const [isComplete, setIsComplete] = useOptimistic(todo.isComplete)

    return (
        <form
            action={async () => {
                setIsComplete(!isComplete)
                await updateTodo(todo.id, !isComplete)
            }}
        >
            <label>
                <input
                    type="checkbox"
                    checked={isComplete}
                    className="todos-checkbox"
                />
                {todo.text}
            </label>
        </form>
    )
}

The isComplete is based on the todo.isComplete, but during the transition, we can change it to !isComplete. Once the transition is finished (whether it was successful or errored out), it will fall back to the value of todo.isComplete.

And the interesting thing about this is we can update optimistic state as many times as we would like during the course of a transition, which means if you have a multi-step action, you could update a message to let the user know what step in the process you’re running in all with the nice declarative model of suspense and transitions.

useFormStatus

Another part of giving users feedback of their form submission is showing them the status. useFormStatus can be used by any components that are underneath a form element.

Think of the `form` element as a context provider and the `useFormStatus` hook as a context consumer.

So you can make a submit button that has access to the current status of its parent form and display a pending state while the form action is in progress:

function SubmitButton() {
    const formStatus = useFormStatus()
    return (
        <button type="submit">
            {formStatus.pending ? 'Creating...' : 'Create'}
        </button>
    )
}

The formStatus has a number of other useful properties that can be used to help implement optimistic UI as well (like the data that’s being submitted).

• 📜 useOptimistic
• 📜 useFormStatus

Optimistic UI

🧝‍♂️ I’ve added a form and some API updates for us to be able to create new ships to add to the page. As usual, you can

if you’re curious what has changed and if you’d like to implement this yourself for some extra practice, feel free to go back to the previous solution and add the form and API updates yourself.

👨‍💼 Thanks Kellie! Ok, so right now, the user experience is not great with the amount of time it takes to create a ship and then display the newly created ship. It definitely would be nice to let the user see as much of their newly created ship as possible while we’re in the process of saving it and loading it.

What we need is a mechanism for turning the user’s submission into a Ship object which we can use to display.

🧝‍♂️ Actually, I already implemented this as well, it’s called createOptimisticShip and accepts a FormData object. So you can use that. You’ll notice the fetchedAt time is set to ’…’ because it’s not technically been fetched yet. This is common for optimistic UI where there’s some data you can’t display until the server response actually comes through. But the rest of the data we get is what we want to display.

👨‍💼 Oh awesome. Great so what you need to do is create an optimistic ship which we can pass to the ShipDetails component to display that while the real data is being retrieved.

You’ll need to store this up in the App component and pass the optimisticShip and setOptimisticShip props down to the CreateForm and ShipDetails components.

Hop to it!

Form Status

👨‍💼 It would be nice if we update the create button with a message letting the user know that we’re in the process of creating their ship and also disable it to prevent the user from clicking it again by mistake.

Can you use useFormStatus to do this?

• 📜 useFormStatus

Multi-step Actions

👨‍💼 Our submit button changes from “Create” to “Creating…” but our form action actually has one more step: loading the newly created ship.

We want to update the message of our submit button to indicate which step we’re on in the process. But updating state during a transition (like that in our form action) isn’t possible. So we need to use useOptimistic. Here’s an example of how you might do this:

<form
    action={async (formData) => {
        setMessage('Creating order...')
        const order = await createOrder(formData)
        setMessage('Creating payment...')
        const payment = await createPayment(formData, order)
        setMessage('Almost done!')
        await sendThankYou(order, payment)
    }}
>
    {/* ...*/}
</form>

So please add a useOptimistic for a “message” variable which we’ll use to update the submit button message. You can initialize it to “Create” and then update it in each step of our form action.

index.css

body {
    margin: 0;
}

* {
    box-sizing: border-box;
}

.app-wrapper {
    display: flex;
    flex-direction: column;
    align-items: center;
    justify-content: center;
    height: 100vh;
}

.ship-buttons {
    display: flex;
    justify-content: space-between;
    width: 300px;
    padding-bottom: 10px;
}

.ship-buttons button {
    border-radius: 2px;
    padding: 2px 4px;
    font-size: 0.75rem;
    background-color: white;
    color: black;
    &:not(.active) {
        box-shadow: 0 0 4px 0 rgba(0, 0, 0, 0.5);
    }
    &.active {
        box-shadow: inset 0 0 4px 0 rgba(0, 0, 0, 0.5);
    }
}

.app {
    display: flex;
    max-width: 1024px;
    border: 1px solid #000;
    border-start-end-radius: 0.5rem;
    border-start-start-radius: 0.5rem;
    border-end-start-radius: 50% 8%;
    border-end-end-radius: 50% 8%;
    overflow: hidden;
}

.search {
    width: 150px;
    max-height: 400px;
    overflow: hidden;
    display: flex;
    flex-direction: column;

    input {
        width: 100%;
        border: 0;
        border-bottom: 1px solid #000;
        padding: 8px;
        line-height: 1.5;
        border-top-left-radius: 0.5rem;
    }

    ul {
        flex: 1;
        list-style: none;
        padding: 4px;
        padding-bottom: 30px;
        margin: 0;
        display: flex;
        flex-direction: column;
        gap: 8px;
        overflow-y: auto;
        li {
            button {
                display: flex;
                align-items: center;
                gap: 4px;
                border: none;
                background-color: transparent;
                &:hover {
                    text-decoration: underline;
                }
                img {
                    width: 20px;
                    height: 20px;
                    object-fit: contain;
                    border-radius: 50%;
                }
            }
        }
    }
}

.details {
    flex: 1;
    height: 400px;
    position: relative;
    overflow: hidden;
}

.ship-info {
    height: 100%;
    width: 300px;
    margin: auto;
    overflow: auto;
    background-color: #eee;
    border-radius: 4px;
    padding: 20px;
    position: relative;
}

.ship-info.ship-loading {
    opacity: 0.6;
}

.ship-info h2 {
    font-weight: bold;
    text-align: center;
    margin-top: 0.3em;
}

.ship-info img {
    width: 100%;
    height: 100%;
    aspect-ratio: 1;
    object-fit: contain;
}

.ship-info .ship-info__img-wrapper {
    margin-top: 20px;
    width: 100%;
    height: 200px;
}

.ship-info .ship-info__fetch-time {
    position: absolute;
    top: 6px;
    right: 10px;
}

.app-error {
    position: relative;
    background-image: url('/img/broken-ship.webp');
    background-size: contain;
    background-repeat: no-repeat;
    background-position: center;
    width: 400px;
    height: 400px;
    p {
        position: absolute;
        top: 30%;
        left: 50%;
        transform: translate(-50%, -50%);
        background-color: white;
        padding: 6px 12px;
        border-radius: 1rem;
        font-size: 1.5rem;
        font-weight: bold;
        width: 300px;
        text-align: center;
    }
}

index.tsx

import { Suspense, use, useOptimistic, useState, useTransition } from 'react'
import { useFormStatus } from 'react-dom'
import * as ReactDOM from 'react-dom/client'
import { ErrorBoundary, type FallbackProps } from 'react-error-boundary'
import { useSpinDelay } from 'spin-delay'
import { type Ship, getShip, createShip } from './utils.tsx'

function App() {
    const [shipName, setShipName] = useState('Dreadnought')
    const [isTransitionPending, startTransition] = useTransition()
    const isPending = useSpinDelay(isTransitionPending, {
        delay: 300,
        minDuration: 350,
    })
    const [optimisticShip, setOptimisticShip] = useOptimistic<Ship | null>(null)

    function handleShipSelection(newShipName: string) {
        startTransition(() => {
            setShipName(newShipName)
        })
    }

    return (
        <div className="app-wrapper">
            <ShipButtons shipName={shipName} onShipSelect={handleShipSelection} />
            <div className="app">
                <div className="details" style={{ opacity: isPending ? 0.6 : 1 }}>
                    <ErrorBoundary fallback={<ShipError shipName={shipName} />}>
                        <Suspense fallback={<ShipFallback shipName={shipName} />}>
                            <ShipDetails shipName={shipName} optimisticShip={optimisticShip} />
                        </Suspense>
                    </ErrorBoundary>
                </div>
            </div>
            <CreateForm
                setOptimisticShip={setOptimisticShip}
                setShipName={setShipName}
            />
        </div>
    )
}

function CreateForm({
    setOptimisticShip,
    setShipName,
}: {
    setOptimisticShip: (ship: Ship | null) => void
    setShipName: (name: string) => void
}) {
    const [message, setMessage] = useOptimistic('Create')
    return (
        <div>
            <p>Create a new ship</p>
            <ErrorBoundary FallbackComponent={FormErrorFallback}>
                <form
                    action={async (formData) => {
                        setMessage('Creating...')
                        setOptimisticShip(await createOptimisticShip(formData))

                        await createShip(formData, 2000)

                        setMessage('Created! Loading...')

                        setShipName(formData.get('name') as string)
                    }}
                >
                    <div>
                        <label htmlFor="shipName">Ship Name</label>
                        <input id="shipName" type="text" name="name" required />
                    </div>
                    <div>
                        <label htmlFor="topSpeed">Top Speed</label>
                        <input id="topSpeed" type="number" name="topSpeed" required />
                    </div>
                    <div>
                        <label htmlFor="image">Image</label>
                        <input
                            id="image"
                            type="file"
                            name="image"
                            accept="image/*"
                            required
                        />
                    </div>
                    <CreateButton>{message}</CreateButton>
                </form>
            </ErrorBoundary>
        </div>
    )
}

function CreateButton({ children }: { children: React.ReactNode }) {
    const { pending } = useFormStatus()
    return (
        <button type="submit" disabled={pending}>
            {children}
        </button>
    )
}

async function createOptimisticShip(formData: FormData) {
    return {
        name: formData.get('name') as string,
        topSpeed: Number(formData.get('topSpeed')),
        image: await fileToDataUrl(formData.get('image') as File),
        weapons: [],
        fetchedAt: '...',
    }
}

function fileToDataUrl(file: File) {
    return new Promise<string>((resolve, reject) => {
        const reader = new FileReader()
        reader.onload = () => resolve(reader.result as string)
        reader.onerror = reject
        reader.readAsDataURL(file)
    })
}

function FormErrorFallback({ error, resetErrorBoundary }: FallbackProps) {
    return (
        <div role="alert">
            There was an error:{' '}
            <pre style={{ color: 'red', whiteSpace: 'normal' }}>{error.message}</pre>
            <button onClick={resetErrorBoundary}>Try again</button>
        </div>
    )
}

function ShipButtons({
    shipName,
    onShipSelect,
}: {
    shipName: string
    onShipSelect: (shipName: string) => void
}) {
    const ships = ['Dreadnought', 'Interceptor', 'Galaxy Cruiser']

    return (
        <div className="ship-buttons">
            {ships.map((ship) => (
                <button
                    key={ship}
                    onClick={() => onShipSelect(ship)}
                    className={shipName === ship ? 'active' : ''}
                >
                    {ship}
                </button>
            ))}
        </div>
    )
}

function ShipDetails({
    shipName,
    optimisticShip,
}: {
    shipName: string
    optimisticShip: Ship | null
}) {
    // 🦉 you can change this delay to control how long loading the resource takes:
    const delay = 2000
    const ship = optimisticShip ?? use(getShip(shipName, delay))
    return (
        <div className="ship-info">
            <div className="ship-info__img-wrapper">
                <img src={ship.image} alt={ship.name} />
            </div>
            <section>
                <h2>
                    {ship.name}
                    <sup>
                        {ship.topSpeed} <small>lyh</small>
                    </sup>
                </h2>
            </section>
            <section>
                {ship.weapons.length ? (
                    <ul>
                        {ship.weapons.map((weapon) => (
                            <li key={weapon.name}>
                                <label>{weapon.name}</label>:{' '}
                                <span>
                                    {weapon.damage} <small>({weapon.type})</small>
                                </span>
                            </li>
                        ))}
                    </ul>
                ) : (
                    <p>NOTE: This ship is not equipped with any weapons.</p>
                )}
            </section>
            <small className="ship-info__fetch-time">{ship.fetchedAt}</small>
        </div>
    )
}

function ShipFallback({ shipName }: { shipName: string }) {
    return (
        <div className="ship-info">
            <div className="ship-info__img-wrapper">
                <img src="/img/fallback-ship.png" alt={shipName} />
            </div>
            <section>
                <h2>
                    {shipName}
                    <sup>
                        XX <small>lyh</small>
                    </sup>
                </h2>
            </section>
            <section>
                <ul>
                    {Array.from({ length: 3 }).map((_, i) => (
                        <li key={i}>
                            <label>loading</label>:{' '}
                            <span>
                                XX <small>(loading)</small>
                            </span>
                        </li>
                    ))}
                </ul>
            </section>
        </div>
    )
}

function ShipError({ shipName }: { shipName: string }) {
    return (
        <div className="ship-info">
            <div className="ship-info__img-wrapper">
                <img src="/img/broken-ship.webp" alt="broken ship" />
            </div>
            <section>
                <h2>There was an error</h2>
            </section>
            <section>There was an error loading "{shipName}"</section>
        </div>
    )
}

const rootEl = document.createElement('div')
document.body.append(rootEl)
ReactDOM.createRoot(rootEl).render(<App />)

utils.tsx

import { type Ship } from './api.server.ts'

export type { Ship }

export async function createShip(formData: FormData, delay?: number) {
    const searchParams = new URLSearchParams()
    if (delay) searchParams.set('delay', String(delay))
    const r = await fetch(`api/create-ship?${searchParams.toString()}`, {
        method: 'POST',
        body: formData,
    })
    if (!r.ok) {
        throw new Error(await r.text())
    }
}

const shipCache = new Map<string, Promise<Ship>>()

export function getShip(name: string, delay?: number) {
    const shipPromise = shipCache.get(name) ?? getShipImpl(name, delay)
    shipCache.set(name, shipPromise)
    return shipPromise
}

async function getShipImpl(name: string, delay?: number) {
    const searchParams = new URLSearchParams({ name })
    if (delay) searchParams.set('delay', String(delay))
    const response = await fetch(`api/get-ship?${searchParams.toString()}`)
    if (!response.ok) {
        return Promise.reject(new Error(await response.text()))
    }
    const ship = await response.json()
    return ship as Ship
}

export function getImageUrlForShip(
    shipName: string,
    { size }: { size: number },
) {
    return `/img/ships/${shipName.toLowerCase().replaceAll(' ', '-')}.webp?size=${size}`
}
